Cryogenic - Ọnya Ọnya Tubular Okpomọkụ maka nrụpụta ike & Nchekwa Ọkụ dị ala -
Maka ngwa nrụpụta ike, ike - na-arụ ọrụ nke ọma spiral ọnya tubular okpomọkụ na-enye uru dị ukwuu. Emebere ya iji nwetaghachi okpomọkụ n'efu site na gas na-ekpochapụ ma ọ bụ uzuoku, na-emeziwanye arụmọrụ ọkụ nke ụlọ ọrụ ọkụ. Ọdịdị tube nke a na-emerụ ahụ na-eme ka ọgbaghara nke mmiri na-eme ka ọ dịkwuo mma, na-eme ka nnyefe okpomọkụ dịkwuo elu site n'ibelata oyi akwa okpomọkụ.
Ewubere site na ihe ndị na-eguzogide elu - okpomọkụ - dị ka igwe anaghị agba nchara na nickel alloys, ọ nwere ike ịrụ ọrụ n'okpuru ọnọdụ dị oke egwu yana okpomọkụ ruru ogo 1000 yana nrụgide nke 8 MPa. N'ime ụlọ ọrụ ọkụ okirikiri - jikọtara ọnụ, ọ na-ebufe ọkụ nke ọma n'etiti mmiri dị iche iche na-arụ ọrụ, na-abawanye mmepụta ike site na 15%. N'oge usoro nrụpụta, igwe igwe ikuku na-achịkwa - na-eme ka oghere tube na-adịgide adịgide na njigide ya, na-ebuli ọrụ ya ma na-atụnye aka na nrụpụta ike na-adigide.
Nkọwa ngwaahịa
Ozi bụ isi
◆ Ebe Mmalite: China
◆ Aha ika: [Enwere ike ịhazi ya, dịka, CryoTech]
◆ Asambodo: ASME BPVC, ISO 9001, NBIC
◆ Nọmba Model: CWHX - P2025
Nchịkọta ngwaahịa
◆ Emebere ya maka nchekwa cryogenic na ike ike, ọnya tubular okpomọkụ na-eji nickel - alloy tubes eguzogide ujo ọkụ. Ọ na-eme atụmatụ shei ọkọlọtọ - na - tube na ngwa dị ala - ma na-eweghachi okpomọkụ mkpofu n'ime ụlọ ọrụ ọkụ, na-akwalite nrụpụta ọkụ. Ọ dị mma maka tankị cryogenic, akụrụngwa LNG, yana osisi ike okirikiri - jikọtara ọnụ.
Nkọwapụta igodo
◆ Ihe eji ewu ụlọ
Tubes: Nickel - alloy (dịka ọmụmaatụ, Inconel 625) maka nkwụghachi azụ cryogenic; igwe anaghị agba nchara 310S maka elu - temp ike osisi ojiji. Na-eguzogide ujo ọkụ (- 196 ogo ruo ogo 1000) yana corrosion sitere na gas/steam iyuzucha.
Shell: Carbon steel ike dị elu - (nhọrọ: igwe anaghị agba nchara duplex maka oke corrosion). Na-eme ka iguzosi ike n'ezi ihe nhazi n'okpuru nrụgide 8 MPa.
◆ Performance Parameters
Oke okpomoku: - 196 ogo (nkwakọba cryogenic) ruo ogo 1000 (ọkụ ọkụ ụlọ ọrụ ọkụ).
Nrịba nrụgide: Ruo 8 MPa (na-ejikwa uzuoku nrụgide dị elu - na okirikiri ike).
Okpomọkụ iweghachite arụmọrụ: Na-ebelata mfu okpomọkụ n'efu site na 40%, na-eme ka nrụpụta ọkụ ọkụ ọkụ ọkụ site na 15% (site na ọgba aghara na tubes ọnya).
Nhazi & arụmọrụ
◆ Cryogenic Resilience
Nickel - ọkpọkọ alloy na-ewepụ ihe egwu egwu ọkụ na ngwa cryogenic (dịka nchekwa LNG, sistemu nitrogen mmiri mmiri). Ọdịdị ọnya ahụ siri ike na-edobe nkwụsi ike na-asọpụta na - 196 ogo, na-egbochi mgbaji tube na-emekarị na nhazi ọkọlọtọ.
◆ Igwe ọkụ na-ekpofu ọkụ na-eweghachite
N'ọgbọ ike, spiral {{0} tubes ọnya na-abawanye ọgbaghara mmiri, na-ebelata oke oke ọkụ. Nke a na-eme ka mbufe ọkụ sitere na gas / uzuoku gaa na mmiri na-arụ ọrụ (dịka ọmụmaatụ, mmiri, mmanụ ọkụ), na-eweghachi okpomọkụ mkpofu iji bulie mmepụta ike site na 15%.
Mpaghara Ngwa
◆ Nchekwa Cryogenic & Ngwa LNG
LNG reasification: Na-ekpo ọkụ cryogenic LNG ka ọ bụrụ ụdị gas na-eji okpomọkụ gburugburu, na-ebelata ike iji na osisi regas.
Nchekwa gas Liquid: Na-edobe okpomoku kwụsiri ike maka nitrogen mmiri mmiri, oxygen na tankị argon, na-egbochi mgbanwe oge.
◆ Ọgbọ Ike
Ngwakọta - Osisi okirikiri: Na-enyefe okpomọkụ n'etiti elu - okpomọkụ iyuzucha (1000 degrees) na uzuoku/mmiri loops, na-eme ka arụmọrụ okirikiri dị elu.
Ihe mkpofu - gaa na - Ngwa ike: na-eweghachi okpomọkụ site na mkpọnyụ ọkụ, na-atụgharị okpomọkụ mkpofu ka ọ bụrụ ọkụ eletrik.
Usoro azụmahịa
◆ Nkọwa nkọwa
Ọnụ ọgụgụ kacha nta (MOQ): 1 unit (na-akwado ọrụ pilot na mpaghara cryogenic / ike; nnukwu iwu Karịrị ma ọ bụ hà nhata 3 nkeji nweta 10% mbelata).
Ahịa: $15,000–$25,000/otu (dị iche iche site na ihe onwunwe: nickel - alloy na-agbakwụnye 20% na-eri vs. igwe anaghị agba nchara).
◆ Mbupu & nnyefe
Nkwakọ ngwaahịa:
Ojiji Cryogenic: ụfụfụ akpọchiri akpọchi + oghere - akpa mechiri emechi iji gbochie ọbịbịa mmiri.
Eji ihe ọkụkụ ọkụ: ihe nkiri VCI na-emegide - corrosion + igwe nchara maka ibu njem nrụgide - dị elu.
Oge nnyefe: 18-25 ụbọchị (ọkọlọtọ); Ụbọchị 30–35 (ụdị nickel - alloy cryogenic ụdị).
◆ Ịkwụ Ụgwọ & Nyefee
Usoro ịkwụ ụgwọ: T/T (40% nkwụnye ego maka nickel - alloy order), L/C na anya.
Ịkwanye ikike: 300 nkeji / ọnwa (ahịrị raara onwe ya nye maka ụdị cryogenic na ike osisi).
